The Sony PMW-200 XDCAM HD422 Camcorder Demo Unit is the successor to Sony's well respected PMW-EX1/R camcorder. It supports the 50 Mbps MPEG HD422 codec and MXF recording. The PMW-200 is equipped with three 1/2" Full HD 1920 x 1080 Exmor CMOS sensors, which support 1000 TV1 high resolution, F11 (2000 lx) high sensitivity, low 56dB noise and a wide dynamic range. It works for SD/HD recording and features a 14x zoom lens with a unique focus ring mechanism. The camera is equipped with dual ExpressCard SxS memory card slots and supports up to four hours of 50 Mbps MPEG HD422 recording. It supports both UDF and FAT file format modes and is switchable between NTSC, NTSC(J), and PAL areas. Other functions include Slow/Quick motion playback, focus magnification, slow shutter, shutter angle settings and picture cache recording. The PMW-200 features four-channel audio recording, as well as HD/SDI, HDMI, and composite/HD-Y outputs. There's six Gamma settings, four HyperGamma settings and a USB port for using the camcorder as a card reader. Three 1/2" Full HD Exmor 3CMOS sensors50 Mbps MPEG HD422 recording as MXF files (UDF mode only)Multi-region support: switchable between NTSC/PAL areaSD recording and playback (DVCAM) standard14x fixed zoom lens (servo/manual switchable) with unique focus ring mechanismTwo ExpressCard SxS memory card slotsRecord up to four hours or 50 Mbps MPEG HD422 in camcorder using two 64 GB SxS-1A memory cards (not included)UDF (Professional Disc compatible) or FAT (XDCAM EX compatible) file format mode shooting in order to have similar high-res files and workflows with existing Professional Disc and XDCAM EX camcordersLow power consumptionCompact and lightweight design for better mobility3.5" (8.9 cm) color LCD display with 16:9 aspect ratioSlow and Quick motionFocus Magnification for focus assistanceShutter Angle SettingsPicture Cache RecordingHigh-quality four-channel audio recordingHD/SD-SDI, HDMI, and composite/HD-Y outputUSB interface for connecting camcorder as card readerSix Standard Gamma settings and four HyperGamma settings

Camera Section
Imaging Device 3 x 1/2" Exmor CMOS Sensors
Effective Picture Elements 1920 x 1080 (HxV)
Slow Shutter 2, 3, 4, 5, 6, 7, 8, 16, 32 and 64-frame accumulation
Sensitivity 2000 lx, 89.9% reflectance (F11 typical)
Gain Selection -3, 0, 3, 6, 9, 12 and 18dB
Recording
Video Recording Format UDF HD Mode

NTSC Area/NTSC(J) Area:
HD422 50 - 1080/59.94i
HD420 HQ - 1080/59.94i
HD422 50 - 1080/29.97p
HD420 HQ - 1080/29.97p
HD422 50 - 1080/23.98p
HD420 HQ - 1080/23.98p
HD422 50 - 720/59.94p
HD420 HQ - 720/59.94p
HD422 50 - 720/29.97p
HD422 50 - 720/23.98p
HD420 HQ - 720/23.98p

PAL Area:
HD422 50 - 1080/50i
HD420 HQ - 1080/50i
HD422 50 - 1080/25p
HD420 HQ - 1080/25p
HD422 50 - 720/50p
HD420 HQ - 720/50p
HD422 50 - 720/25p

UDF SD Mode

NTSC Area/NTSC(J) Area:
DVCAM59.94i SQ
DVCAM59.94i EC
DVCAM29.97p SQ
DVCAM29.97p EC

PAL Area:
DVCAM59.94i SQ
DVCAM59.94i EC
DVCAM29.97p SQ
DVCAM29.97P EC

FAT HD Mode

NTSC Area/NTSC(J) Area:
HQ 1920/59.94i
HQ 1440/59.94i
SP 1440/59.94i
HQ 1920/29.97p
HQ 1440/29.97p
HQ 1920/23.98p
HQ 1440/23.98p
SP 1440/23.98p
HQ 1280/59.94p
HQ 1280/29.97p
HQ 1280/23.98p

PAL Area:
HQ 1920/50i
HQ 1440/50i
SP 1440/50i
HQ 1920/25p
HQ 1440/25p
HQ 1280/50p
HQ 1280/25p

FAT SD Mode

NTSC Area/NTSC(J) Area:
HQ 1920/50i
HQ 1440/50i
SP 1440/50i
HQ 1920/25p
HQ 1440/25p
HQ 1280/50p
HQ 1280/25p

PAL Area:
DVCAM50i SQ
DVCAM50i EC
DVCAM25p SQ
DVCAM25p EC
Audio Recording UDF Mode (HD Recording)
MPEG HD422 (MPEG-2 422P@HL):
4 channels, 48 kHz (24-bit LPCM)
MPEG HD420 (1440 x 1080, MPEG-2 MP@HL):
4 channels, 48 kHz (16-bit LPCM)
UDF Mode (SD Recording)
DVCAM: 4 channels, 48 kHz (16-bit)
FAT Mode (HD Recording)
MPEG HD420 (1920 x 1080, MPEG-2 MP@HL):
2 channels, 48 kHz (16-bit LPCM)
Fat Mode (SD Recording)
DVCAM: 2 channels, 48 kHz (16-bit LPCM)
Recording Media SxS Express 34 Cards (SBP-8/16/32GB)
Recording Time (UDF Mode) 50 Mbps MPEG HD422 (MPEG-2 422P@HL)
Approx. 120 min with 64 GB SxS memory card
Approx. 60 min with 32 GB SxS memory card
Approx. 30 min with 16 GB SxS memory card



35 Mbps VBR, HQ Mode MPEG HD420 (1440x1080, MPEG-2 MP@HL)Approx. 180 min with 64 GB SxS memory card
Approx. 90 min with 32 GB SxS memory card
Approx. 45 min with 16 GB SxS memory card



25 Mbps DVCAM
Approx. 220 min with 64 GB SxS memory card
Approx. 110 min with 32 GB SxS memory card
Approx. 55 min with 16 GB SxS memory card
Recording Time (FAT Mode) 35 Mbps VBR, HQ Mode - MPEG HD420 (MPEG-2 MP@HL)
Approx. 200 min with 64 GB SxS memory card
Approx. 100 min with 32 GB SxS memory card
Approx. 50 min with 16 GB SxS memory card



25 Mbps CBR, SP Mode - MPEG HD 420 (MPEG-2 MP@HL-14)
Approx. 280 min with 64 GB SxS memory card
Approx. 140 min with 32 GB SxS memory card
Approx. 70 min with 16 GB SxS memory card



25 Mbps DVCAM
Approx. 220 min with 64 GB SxS memory card
Approx. 110 min with 32 GB SxS memory card
Approx. 55 min with 16 GB SxS memory card
Inputs/Outputs
Genlock Input 1 x BNC (switchable to composite video out), 1.0 Vp-p, 75 ohms
TC Input 1 x BNC (switchable to TC Out), 0.5-1.8 Vp-p, 10 kohms
Audio Input 2 x 3-pin female XLR (line, mic, mic +48 V selectable)
SDI Output 1 x BNC (HD/SD switchable)
HDMI Output 1 x Type A
Composite Video Output 1 x BNC (switchable to Genlock In), HD-Y / composite switchable, 1.0 Vp-p, 75 ohms
Audio Output 1 x A/V output jack (10-pin connector)
TC Output 1 x BNC (switchable to TC In), 1.0 Vp-p, 10 kohms
Headphone Jack 1 x 3.5 mm mini-jack (stereo)
Speaker 1 x monaural 250 mW monitor speaker
Microphone 1 x omni-directional stereo electret condenser microphone
DV I/O (i.LINK) 1 x 4-pin IEEE-1394 HDV (HDV 1080i) / DV I/O, S400
USB Port 1 x USB 2.0 (device), mini-B type
Lens
Zoom Ratio 14x (optical) (servo/manual)
Focal Length 5.8 - 81.2 mm
Aperture f/1.9 - f/16 (auto/manual selectable)
Focus AF/MF/Full MF selectable
Macro
Monitoring
Viewfinder Electric Viewfinder (EVF)
Approx 1.2 million pixels
852 x 3 x 480 (HxRGBxV)
LCD Monitor 3.5" (8.9 cm) color LCD
852 x 3 x 480 (HxRGBxV)
Aspect Ratio: 16:9
General Specifications
Media Type 2 x ExpressCard/34 slots
Power Requirements DC 12 V
Power Consumption 13 W (runs up to 4 hrs using BP-U60 battery)
Operating Temperature 32 to 104F (0 to 40C)
Storage Temperature -4 to 140F (20 to 60C)
Humidity 10 to 90% (relative humidity)
Dimensions (WxHxD) 6.9 x 6.5 x 16.5" (172 x 164 x 419 mm)
